HA411G 1GE GPON/XPON ONU

 Comply with ITU-T G 984.1/2/3/4 Standard Support 984 standard AES128 encryption function Plug and play, integrated auto-detecting, auto-configuration, and auto firmware upgrade, etc Integrated remote configuration and maintenance function. Fully

Version:HA411G

Color:Black

Battery:

Function:

Accessories:

Online consultation

Service hotline::

0086-0755-83128820

Product Description Specification

HA411G GPON ONU is designed for fulfilling FTTH ultra-broadband access request of home and SOHO users. It is based on the stable and mature GPON technology, which has high performance/price ratio, and the technology of layer 2 Ethernet switch as well. It is highly reliable and easy to maintain, with guaranteed QoS, and fully compliant to ITU-T G.984 GPON standards.




Technical Parameter



Technical items

Description

Main chip

RTL

Uplink PON interface

1 GPON interface, SC single-mode/single-fibre, uplink 1.25Gbps, downlink 2.5Gbps

Downlink  LAN interface

1* 10/100/1000Mbps Auto adaptive Ethernet interface,

Full Duplex/Half Duplex, RJ45 connector

Wavelength

Tx 1310nm, Rx 1490nm

Split ratio

1:64

Gateway function

Router mode supports PPPoE/DHCP/ static IP

WAN support Route rand Bridge mode

WAN support Internet,VoIP,IPTV

LAN supports DHCP and static IP

Support NAT and NAPT

DC power supply

+12Vdc, 0.5A, external AC-DC adaptor

Power consumption

≤3W

Operating condition

Operating temp: -5~+45℃

Operating humidity:10~90%(non-condensed)

Storing condition

Storing temp: -40~+70℃

Storing humidity:10~90%(non-condensed)

Dimension

105mm(length) * 78mm(width) * 24mm(height)

Net weight

0.2Kg
